Varillaje Rotación, Rotopercusión y Micropilotes. · Diferentes Diámetros: 152 mm., 180 mm., 200 mm., y 253 mm. · Diferentes Longitudes: 1000, 1500 y 2000
Mesa de coordenadas manual con diferentes posibilidades y tamaños para adaptarse a cualquier tipo de máquina: taladros, fresadoras, etc. · La características común de todas las mesas es un diseño ergonómico, con protección y engrasadores exteriores para husillos, tuercas y guías. Las tuercas son autoajustables y se fabrican en varias medidas, para adaptarse lo mejor posible a la máquina que complementa. · En el siguiente detalle se identifican las partes principales de las mesas de coordenadas manuales: · Pitón sensibilidad · Volante con tuerca de seguridad · Caja de desagüe (mod. 430/600/800/1000) · Lubricación de guías · Protección de guías y husillo · Mesas de coordenadas manuales, detalles de sus partes · Accesorios opcionales: · Regla de topes regulables · 6 tacos de caucho en "T" y 2 Racores 3/8" para recogida y salida de refrigerante. · Regla de topes regulables en movimineto longitudinal. · Movimiento en EJE X · Movimiento en EJE X giratonia · Movimiento en EJES X-Y · Movimiento en EJES X-Y giratoria ... Leer más
La protección para taladros ERLO es una protección fabricada en policarbonato, regulable en altura, completa con microinterruptor de seguridad. · Grosor del policarbonato: 4mm · Peso: 2kgs. · Grado de protección: IP67 · Protecciones
Las protecciones de seguridad para taladro, son indispensables para la correcta protección del operario durante el uso de la máquina. Básicamente, debemos tener en cuenta tres puntos de seguridad para taladros: · Protección enclavada del acceso a la broca · Protección del acceso a la correa de transmisión (fija o enclavado) · Pulsador de parada de emergencia · Por la diversidad de modelos en el mercado y diferentes espacios o zonas más cómodas para enclavar; hay diversos tipos de carcasas, siendo las más habituales las de los taladros ERLO o IBARMIA que son los que tradicionalmente se han comercializado a nivel industrial: · Protección para taladros ERLO · Protección para taladros IBARMIA · Protección para otros taladros ... Leer más
Barras helicoidales Ø 210 mm - 19 Uds. x 1,50 m - Total: 28,5 m · Barras helicoidales Ø 300 mm - 3 Uds x 1,5 + 3 Uds. x 1 m + 1 Uds. x 50 cm - Total 8 metros · precio base - Hay que sumarle impuestos
Technical characteristics · The composition of this CNC is the following :- 3-axis horizontal ripper unit. Motor power: 3.3 kW- 3-axis vertical routing unit. Motor power: 3.3 kW- 3-axis drilling unitMaximum machining dimension :- Length: 4.000 mm- Width: 200 mm- Height: 150 mmSuction outlet : 1 out of 200 mmAir pressure: 6,5 barComputer : Windows 98Power and Motors :- Electrical power : 8Kw - Voltage : Three-phase 400V (3 phases + earth, 6mm2)- Intensity : 15AIncluded in the sales price:- Machine user manual, in English- Machine programming manual, in English- Manual for setting machine parameters according to machining requirements- Electrical diagrams- Description of error codes and possible solutions, in French · Power and Motors · Pluging: Three-phased · Overall dimensions · Lenght: 4600 mmWidth: 2100 mmHeight: 2000 mmWeight: 1500 Kg ... Leer más
Technical characteristics · Magazine for automatic hinge distributionMulti-spindle head (2 spindles 50 mm apart + 1 central spindle 36 mm in diameter)Worktop with 5 aluminum profilesWorktop dimensions : 2500 x 600 mm10 pneumatic stops + cylinder with 4 stopsStop action via front-mounted controlsCycle start via foot pedal · Power and Motors · Voltage: 380 VPluging: Three-phased · Overall dimensions · Lenght: 2500 mmWidth: 1000 mm ... Leer más
Technical characteristics · Single column unloader with suction cups. It is suitable for unloading in machining lines requiring machines with reduced dimensions.BODY OF THE MACHINEThe machine is composed of a vertical column, a horizontal bracket fixed to the carriage, a carriage fixed to the bracket and a suction cup holder frame unit. The carriage slides on linear guides equipped with ball bearings and is driven by a gear motor controlled by a frequency variator.SUCTION CUPS PANEL COLLECTION GROUPIt consists of a suction cups row containing 10 suction cups with bellows to facilitate the separation of the panel. Suction cup diameter of 95 mm. The suction cups are operated by a vacuum pump with a flow rate of 22 m3/h.ELECTRICAL CABINETThe machine is equipped with a separate electrical cabinet, managed by a PLC operating logic.PROTECTIONS FOR THE PREVENTION OF WORK ACCIDENTSThe machine is protected on all the action perimeter of the suction cups group by protective panels. The battery insertion area is protected by a grid with button opening.DIMENSIONS OF THE WORKABLE PANELS :Length: 320 to 2700 mmWidth : 250 to 700 mmThickness : 12 to 50 mmMaximum weight : 50 kg Pneumatic brake idler roller LOAD TRANSFER IN SINGLE LONGITUDINAL ROWTransfer of introduction with inclined rollers to the left, covered in PVC. The rollers are driven by small belts activated by a gear motor under the control of a speed variator. The transfer is also equipped with a left hand guide adjustable by handwheel.StructureThe structure is made of welded steel, reinforced to ensure maximum stability and precision during the operating phases.Work surfaceThe worktop is made up of a transfer in four independent sections.The first section includes :An input transfer with flat belts driven by an asynchronous motor controlled by a frequency converterThe second and third sections (drilling planes) each include:A belt transfer with: flat belts driven by asynchronous motor controlled by frequency converterA lateral reference guide, installed on the left side of the machine, with lateral stop function Pneumatic end stops for the positioning of right and left panelsA lateral presser guide to guide and clamp panels of different widths against the lateral reference stop.The fourth section includes:a belt transfer for the evacuation of the panels with :flat belts driven by asynchronous motor controlled by frequency checker.Machining centerThe first center consists of a mobile carriage along the X axis on which two independent drilling heads are installed along the Y and Z axes.Each drilling head is composed as follows:In the X direction, 10 independent vertical chucksIn the direction of the Y axis, 9 independent vertical mandrelsThe second center consists of a mobile carriage along the X axis on which two independent drilling heads are installed along the Y and Z axes.Each drilling head is composed as follows:In the X direction, 10 independent vertical chucksIn the Y direction, 9 independent vertical spindles.Each operating head is suitable for the installation of an additional operating unit to be chosen as an optionAxis movementsPrecision linear guides with circulating ball bearings and brushless motors for X,Y,Z axes.Rectified helical rack coupled to two pinions to allow the recovery of the play along the X axis.Hardened and ground ball screw (Y,Z axis).Pneumatic balancing device (Z axis) of the drilling unit.Numerical controlXNC model based on PC platform and Multitask Real-Time operating systemAutomatic centralized lubrication system.At each adjustable time interval by numerical control the lubricant is automatically sent to all linear guides and ball screws.MOTORIZED ROLLER CONVEYOR WITH TRACKSThe conveyor consists of a structure made of aluminium profiles. On this structure are mounted the rollers, covered in PVC and motorized by means of a shaft that transmits the movement to the rollers via appropriate tracks. The motorization takes place through a gear motor under the control of a variable speed drive.Automatic drilling and threading machine with numerical control and two machining centersStructureThe two end beams are made of welded steel to ensure stability and precision during the machining operations, the transport system is made of aluminum profiles.Work surfaceThe working plane is composed by a transport system with 4 sectionsThe first section consists ofA retractable entry transferFlat belts driven by an asynchronous motor with variable speed managed by frequency converterThe second and third sections are the machining areas and consist ofCalibrated roller transfer driven by an asynchronous motor with variable speed managed by frequency converterLateral reference guide positioned on the left side of the machinePneumatic retractable end stops for the positioning of the panels to be machinedLateral pushers able to block against the reference guide panels of different widthsVertical presses to ensure the position of the panels during the machining operations.The fourth section consists of:A retractable output transferFlat belts driven by an asynchronous motor with variable speed managed by frequency converterMovement of the axesHigh precision linear guides with circulating ball bearings, brushless motors for the Y and Z axesHardened and ground recirculating ball screws for the Y and Z axesThread rolling and gluing unitConfigured for feeding and gluing 8mm dowels, composed of :Vibrating bowlAnti-noise coverDevice for detecting lack of trunnionsHigh pressure pump for glue feedingElectronic control devices and specific softwareAutomatic centralized lubrication system.Lubricant is automatically sent to all linear guides and ball screws at each programmable time interval by digital control.Single column unloader with suction cups. It is suitable for unloading in machining lines requiring machines with reduced dimensions.BODY OF THE MACHINEThe machine is composed of a vertical column, a horizontal bracket fixed to the carriage, a carriage fixed to the bracket and a suction cup holder frame group. The carriage slides on linear guides equipped with ball bearings and is driven by a gear motor controlled by a frequency variator.SUCTION CUPS PANEL COLLECTION GROUPIt consists of a suction cups row containing 10 suction cups with bellows to facilitate the separation of the panel. Suction cup diameter of 95 mm. The suction cups are operated by a vacuum pump with a flow rate of 22 m3/h.ELECTRICAL CABINETThe machine is equipped with a separate electrical cabinet, managed by a PLC operating logic.PROTECTIONS FOR THE PREVENTION OF WORK ACCIDENTSThe machine is protected on all the action perimeter of the suction cups group by protective panels. The battery insertion area is protected by a grid with button opening. · Power and Motors · Overall dimensions ... Leer más
PAGANI T73-200 · PRUEBAS PENETROMÉTRICAS ESTÁTICAS Y DINÁMICAS CON UNA ÚNICA MÁQUINA · HORAS 1.800 · · La TG73-200 está construida sobre un carro de orugas autopropulsado de tracción hidráulica que permite la MÁS AMPLIA MOVILIDAD, INCLUSO EN TERRENOS IRREGULARES Con sus tres estabilizadores y el mástil inclinable, la TG73-200 puede trabajar también en laderas muy inclinadas, · manteniendo siempre perfectamente vertical el eje de penetración y de anclaje. · · La TG73-200 puede configurarse a petición para pruebas penetrométricas estáticas (200kN), o estáticas/dinámicas (rendimiento medio dinámico 78%). Las pruebas estáticas pueden efectuarse con punta mecánica (CPTm) o utilizando puntas diferentes como el piezocono (CPTu), también combinado con una sonda sísmica (S-CPTu) lo cual permite una mejor interpretación del suelo. La modalidad estática/dinámica permite obtener información a lo largo de áreas verticales constituidas por terrenos con diferentes características mecánicas (desde muy blandos a muy duros y compactos), mientras que el paso a través de capas especialmente duras es posible gracias a un cabezal de rotación (opcional) que permite la ejecución de preorificios. · · IMPUESTOS NO INCLUIDOS ... Leer más
